“Open A” AEA Tuning on your Cigar Box Guitar: 4 Methods, with String Sizes & Sound Clips

Everything you need to know about using the “Open A” A-E-A tuning on your 3-string cigar box guitar.

This article gives you the exact strings to use to achieve this tuning on a cigar box guitar (or other instrument) that has a scale length in the range of 24.5 to 25.5 inches.

Cigar Box Guitar StringsNot as widely used as some of the other open “power chord” 1-5-1 tunings, the A E A tuning is still a good one to try out and have in your toolbag. A full step higher than the more widely-seen Open G tuning, the high A note can be a bit too trebly for some people, but the lower tuning with the unwound .016″ as the middle A puts out a really nice sound.

First, a disclaimer: these recommendations are made based on our experimentation in the C. B. Gitty shops, and it is what we have found to work. Other people may have different opinions, and they are welcome to them. I’m not trying to set any standards or lay down any laws – I am just going to tell you what works for us.

Check out the various string sets available over at www.CBGitty.com!

The Four Possible AEA Tunings

Basically, on a 3-string cigar box guitar with a scale length in the range of 24 to 25 1/2 inches (scale length being the distance between the nut and the bridge), there are 4 different configurations of AEA that you can have, ranging from the bassiest to the most trebly. Theoretically there are more potential combinations, but we’re just focusing on the cases where you have 3 strings of different sizes, strung from low to high pitch:

  1. Low – Middle – Middle (Low A, Middle E, Middle A)
  2. Low-Middle-High (Low A, Middle E, High A)
  3. Low-High-High (Low A, High E, High A)
  4. Middle-High-High (Middle A, High E, High A)

34-203-02 Product Image 3Each one of these will have a different overall sound and feel – all four use a mix of wound and unwound strings, and range from the bassiest (#1 up to the highest-pitched (#4).

Deciding which option is right for you is mostly a matter of preference, and experimentation. All four can be used to play tablature and lessons intended for guitars tuned to GDG – it will just be one step higher when played. You have to decide whether you want the low growly bass of the low strings, the treble of the high strings, or a mix).

Just Looking for Gitty’s Recommendation? Here You Go…

If I had to arbitrarily make a recommendation of which one you should use, I would probably go with #1B: Low A, Middle E, Middle A (unwound). I just don’t personally like that high A note, it sounds too shrill. That may be partly due to the cigar box guitar I was using to test these tunings – different CBGs resonate better at different frequencies. But I really liked how that lower tuning sounded with that unwound string on top. Listen to the clips below and see what you think!



Now, on to Strings

Basically, there are 5 potential strings that are needed to achieve these 4 tunings. They are:

  1. Low A
  2. Middle E
  3. Middle A
  4. High E
  5. High A

If you think of a standard 6-string guitar, or if you want to use a standard guitar string pack to do these tunings, you can think of it like this:

  1. Low A – use the low A string (second biggest wound string).
  2. Middle E – Tune the wound D string on a standard guitar – third biggest wound string – up a full step.
  3. Middle A – Tune the middle G string on a standard guitar up a full step, or use the unwound B string down a full step.
  4. High E – This is the same as the high E string (smallest unwound string) on a standard guitar.
  5. High A – Unfortunately there is no equivalent string in a standard 6-string guitar pack that will reach this note..

Nickel-wound Electric Guitar Strings

String Weights and Gauges

If you want to know recommended string gauges for buying in bulk, then the chart below should help you pick out the specific gauges you’ll need. Remember that moving to a larger string gauge means you’ll have to crank it tighter to reach the same pitch, compared to a smaller gauge.

Also remember that the chart below is specifically for “standard” scale instruments, that fall an inch or so on either side of a 25″ scale length.

We give both “heavy”, “medium” and “light” recommendations  below, so you can pick a set best suited to your instrument. Heavier strings will have to be cranked tighter than light string sets to reach the right pitch, and this will put more tension on your guitar, bowing your neck more, etc. I recommend starting with the lighter gauge strings and experimenting from there.

These sizes should work with both acoustic and electric guitar strings. Generally electric guitars are strung on the lighter gauge size. The gauges below are hyperlinked to the bulk strings listings at CBGitty.com, where available.

Desired Note/Pitch Light Gauge Medium Gauge Heavy Gauge
Low A .040″ Wound .042″ Wound .044″+ Wound
Middle E .026″ Wound .028″ Wound .030″+ Wound
Middle A(Two options) .016″ Plain Steel or .018″ Wound .017″ Plain Steel or .020″ Wound .018″ Plain Steel or .020″+ Wound*
High E .010″ Plain Steel .011″Plain Steel .012″+ Plain Steel
High A .008″ Plain Steel .008 Plain Steel .009″+ Plain Steel**

*If you can get a .022″ string to hit middle A at 25″ scale length, more power to you! Ours broke almost every time when we tried.

** Getting a .009″ up to high A at 25″ scale length is definitely pushing it… I recommend sticking with .008″ for high A.

Finally! Specific String Size Sets for Specific Tunings

So from all of this, we can get some recommended string sizes to achieve the 4 tunings mentioned above. For this example I’ll list the “Light Gauge” sizes, but you should be able to easily pick out the medium or heavy gauge sizes if you want.

1A) OPTION 1: Low A – Middle E – Middle A: .040″ Wound, .026″ Wound, .018″ WOUND

1B)OPTION 2Low A – Middle E – Middle A: .040″ Wound, .026″ Wound, .016″ UNWOUND

2) Low A – Middle E – High A: .040″ Wound, .026″ Wound, .008″ Plain Steel

3) Low A – High E – High A: .040″ Wound, .010″ Plain Steel, .008″ Plain Steel

4) Middle A – High E – High A: .018″ Wound, .010″ Plain steel, .008″ Plain Steel



The Wiggle Room Factor: you can generally get by with a little larger or little smaller string for any given pitch. Each string has its ideal tension zone, but the edges of that zone are a bit gray. If you keep breaking a string trying to hit Ben "C. B. Gitty" Bakera particular pitch, try a smaller gauge string! If a string seems too loose and flappy, move to a larger gauge string.

Be sure to check out our other articles on cigar box guitar tunings for more great info, sound clips and how-to!
